DS-2AE5223TI-A Hikvision PTZ Dome camera price

৳ 42,300.00

DS-2AE5223TI-A
HD1080P Turbo IR PTZ Dome Camera

DS-2AE5223TI-A Hikvision PTZ Dome camera price in Bangladesh | Hikvision HDTVI Camera distributor in Bangladesh | Hikvision service provider in Bangladesh | Hikvision 1MP IP Camera distributor in Bangladesh | Hikvision 2MP IP Camera distributor in Bangladesh | Hikvision 3MP IP Camera distributor in Bangladesh | Hikvision 4MP IP Camera distributor in Bangladesh |

 DS-2AE5223TI-A Hikvision PTZ Dome camera price

Camera
Image Sensor:|1/3″ Progressive Scan CMOS
Effective Pixels:|1920(H)x1080(V)
Signal System:|PAL/NTSC
Minimum Illumination:|Color: 0.05Lux@(F1.4,AGC ON)
B/W: 0.005Lux@(F1.4,AGC ON)
White Balance:|Auto / Manual / ATW / Indoor / Outdoor
AGC:|Auto/Manual
BLC:|ON/OFF
WDR:|DWDR
Shutter Time:|PAL: 1-1/10,000s
NTSC: 1-1/10,000s
Day& Night:|ICR
Digital Zoom:|16x
Privacy Masking:|8 privacy masks programmable
Auto Focus:|Auto / Semi-automatic / Manual
Lens
Focal Length:|4-92mm, 23x
Zoom Speed:|Approx.3.0s(Optical Wide-Tele)
Angle of View:|49-2.2 degree (Wide-Tele)
Minimum Working Distance:|10-1000mm(Wide-Tele)
Aperture Range:|F1.4~F3.5
Pan & Tilt
Pan Range:|360°endless
Pan Speed:|Pan Manual Speed: 0.1°-250°/s,
Pan Preset Speed: 300°/s
Tilt Range:|-5°~90° (Auto Flip )
Tilt Speed:|Tilt Manual Speed: 0.1°-150°/s,
Tilt Preset Speed: 200°/s
Proportional Zoom:|Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset:|256
Patrol:|8 patrols, up to 32 presets per patrol
Pattern:|4 patterns, with the recording time not less than 10 minutes per pattern
Power loss recovery:|Support
Park Action:|Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display:|ON/OFF
Freeze Frame:|Support
Alarm
Alarm Input:|2
Alarm Output:|1
Input & Output
Turbo HD Output:|1 turbo HD1080p output, BNC
Monitor Output:|1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC
General
RS-485 Protocols:|HIKVISION, Pelco-P, Pelco-D, self-adaptive
Menu Language:|English / Chinese
Power Supply:|24V AC
Power Consumption:|Max. 20W (Heater On), Max. 12W(Heater Off)
Working Temperature/Humidity:|-30 °C-65°C(-22°F-149°F)
90% or less
Protection Level:|IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection
Dimensions:|Φ185mm)×330(mm) (Φ7.28”×12.99”)
Weight (approx.):|4kg (8.81Ibs)
Mount Option:|Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole;
Power box mount:DS-1602ZJ-box;Swan-neck mount: DS-1619ZJ
