Dahua DH-HAC-HFW1509MHP-A-LED 5MP HDCVI Camera

  • Model: DH-HAC-HFW1509MHP-A-LED HDCVI
  • Max 25 [email protected] (16:9 video output), IP67 Water Rating
  • 120 dB true WDR, 3D NR, Built-in mic
  • 50 m illumination distance, 24/7 color imaging
  • 3.6 mm fixed lens,Field of View: H: 88; V: 46°; D: 104°
SKU: 11053 Categories: ,

Dahua DH-HAC-HFW1509MHP-A-LED 5MP Color HDCVI Bullet Camera cost available to be purchased in BD. Are you searching for a Security camera for your home, we are a CCTV Camera seller in Bangladesh and are introducing the best CC Camera Brand in Bangladesh. CCTV package with installation services is provided by Credible Technology with the Best CCTV Camera price for homes, industry, and offices.

Dahua DH-HAC-HFW1509MHP-A-LED 5MP HDCVI Camera

Specification

General
Casing Metal front cover + plastic main body + plastic bracket
Dimensions 304 mm × 108.4 mm × 90.8 mm (11.97″ × 4.27″ × 3.57″)
Weight Net Weight: 0.82 kg (1.8 lb)

Gross Weight: 1.25kg (2.8 lb)

Pan/Tilt/Rotation Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Operating Conditions –40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
Storage Conditions –40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
Power Supply 12 V ±30% DC
Power Consumption Max 6.4 W (12 V DC, warm light on)
Camera
Image Sensor 5MP CMOS
Effective Pixels 5MP
Scanning System Progressive
Electronic Shutter Speed PAL:1/3 s–1/100,000 s
NTSC:1/4 s–1/100,000 s
Minimum Illumination 0.001 Lux/F1.0, 0 Lux warm light on
S/N Ratio > 65 dB
Lens
Lens Type Fixed lens
Mount Type M12
Focal Length 3.6 mm; 6 mm
Max Aperture F1.0
Angle of View 3.6 mm: H: 88; V: 46°; D: 104°
6mm: H: 59; V: 32°; D: 67°
Close Focus Distance 3.6 mm: 2.3 m (7.5 ft)
6mm:4.5m (14.8 ft)
Video
Resolution 2880 (H) × 1620 (V)
Frame Rate TVI:
PAL: [email protected] fps;
NTSC: [email protected] fps
CVBS:
PAL: 960H;
NTSC: 960H
Video Output CVI/TVI/AHD/CVBS by one BNC port
BLC Mode BLC/HLC/WDR/HLC-Pro
Gain Control Auto; Manual
Noise Reduction 3D NR
Interface
Audio Interface One channel built-in mic
Video Interface CVI/TVI/AHD/CVBS by one BNC port
Warranty
Warranty 01-year warranty
