HD-920-UNK skype conference room camera

৳ 1

USB PTZ video conferencing camera

Description

HD-920-UNK skype conference room camera -skype for business meeting room solution

HD-920-UNK skype for business video conferencing hardware



Features:
* Full HD Color Video PTZ Camera 1080P@30, 1080P@25, 1080i@60, 1080i@50, 720P@60, 720P@50, 720P@30, 720P@25
* Image Sensor : 1/2.8″ Type Exmor CMOS
* Zoom : 20 Optical x 12 Optical zoom
* Pan Rotation Angle : 355° Pan,
* Tilt Rotation Angle : 45° Tilt
* Video Output : USB 3.0
* Power ON-OFF switch
* Auto/Manual focus/brightness/WB
* RS-232C/VISCA Protocol

Sensor
Image Sensor1/2.8 Type ExmorCMOS
Effective Pix3.27 Megapixel
Min. Illumination0.1Lux
White balanceAuto/Manual
Gain controlAuto/Manual
Backlight compensationOn/Off
Shutter speed1/1 – 1/10,000S
S/N ratio>50db
LensFocusf=4.7-90mmF1.6-3.5
IrisAuto/Manual
Lens20x Optical x 12 Digital Zoom
Horizontal view angle55.4°
Video outputUSB3.0
Signal system1080P@30,1080P@25,
1080i@60,1080i@50,
720P@60,720P@50 ,720P@30, 720P@25 ,PAL ,NTSC
Control terminalEIA/RS232C,EIA/RS485(Bidirectional)
Control ProtocolVISCA,PELCO-D
baud rate9600/38400bps
patrol line4 cruise sequence
preset position64 preset positions
Speed MatchPan/Tilt movement speed depends on camera module zoom in/out
OSD MenuAccess to OSD Menu and adjust camera module parameters
Image auto flpSupport Horizontal/Vertical image flip
Pan movement speed1-60°/Second
Tilt movement speed1-200 degree per second
Pan movement range1-150 degree per second
Tilt movement rangeUp: 45 degree, Down: 45 degree
Pan scanning automaticallySupport Pan scanning automatically
Boundary scanning0-355 degree (programmable)
Remote controllerIR Wireless Remote controller P/T/Z
Power supplyDC12V,2A
L x W x H250mm x 140mm x 154mm
Weight1380g
